ZX-1 Power Add-on by Spinergy

ZX-1 Power Add-on by Spinergy

(2 reviews)

Price is not the only factor to consider when buying the ZX-1 Power Add-on, the fast delivery from Sportaid is a crowd pleaser!



Your manual wheelchair can transform into a super cool powered chair using the revolutionary ZX-1 power add-on unit. Even if you are a quadraplegic can push a manual chair on fairly level ground with no trouble, the Spinergy ZX-1 can provide powered mobility for complete independence in more varied environments. It’s also a great choice for Paraplegics wanting to save shoulder strength or take advantage of an occasional boost can also benefit from the ZX-1 Power Add-on. The ZX-1 by Spinergy is stealth, lightweight, highly maneuverable, and connects to an array of different chairs from a myriad of manufacturers with absolutely no modifications to the manual chair. It can be adjusted to fit any width chair from 15” to 20”. It can be connected quickly and easily via joystick control. Get where you need to go independently, release and park the ZX-1 if you wish. Use it every day or for occasions such as getting to a soccer field to watch your kids game.



Includes:

  • 2 Drive wheels with tires (10” x 4”)
  • 2 Batteries (12v 15ah AGM)
  • 2 Armrests
  • Joystick & power modules
  • Carbon fiber shroud
  • Battery charger
  • Product/Service manuals



Control System:

Joystick can be operated turning right and left and right hand. ZX-1 Power Add-on can be fully attached to the manual chair without using tools or fasteners.





**Discontinued.  See Max Mobility Smart Drive #MA-SMART, as possible substitute. www.sportaid.com/smartdrive-power-assist-by-max-mobility.html**

Product details
Stock#
ZX-1
Cost:
Wheelchair Manufacturer/Model
Serial Number of Wheelchair
Tire Profile Size
Rear Wheel Size
Rear Seat Width
Camber
Center of Gravity
Backrest Type
User Weight
Camber Tube Diameter
Wheelchair Anti-Tip Device
Yes
No
Wheelchair Arm Rest Hardware
Yes
No
Unobstructed Camber Tube Length
Learn more
Seat Height Adjustment Post Height
Learn more
Joystick Mount
Joystick Style
Learn more
Armrest
Tires
Learn more
Travel Case
Learn more
Batteries
Shipping

Cost:
Qty Out of stock
Click here to subscribe for 'Back-in-stock' notifications
Click here to be notified when this item is nearly out of stock
: *
: *
: *

ROHO Nexus-Spirit Wheelchair Cushion Cover
$53.00
Rusch Closed System Female Catheter - Kit 14Fr
$6.50
Urocare Clear Vinyl Drainage Tubing 8.50" long, 9/32" I.D
$5.50
Wheelchair Transfer Boards - 8 x 24 - 2 Hand Holes
$45.00
$99.00
Pride Victory 10, 4 Wheeled Scooter - FDA Class II Medical Device
$2,189.00
32" Aluminum Folding Reacher with Magnetic Tip Folding
$14.50
Spinergy SPOX Sport X-Laced XSL Wheelchair Wheels
$859.50
Top End Ultimate Pickleball Chair
$4,299.00
Average customer rating:

(2 reviews)



2 Most useful customer reviews (see all reviews):
Sam Harrison
I have been using the zx-1 for almost 3 years now. I purchased one of the first ones made from the inventor. It has been extremely durable, reliable, and very, very useful. As a C5 quad, the zx-1 has, unequivocally, changed my quality of life for the better. I've taken it in snow, over grass, across the country, in cars, in my ramp van, etc. Just went to the park today with my 5 year old, in fact! If you are a quad or para, this will give you the freedom without sacrificing your pride. I'm in a tilite zr. Aand, it's WAY better than e-motion wheels. I've used both. If you got the money, buy it. You're welcome.
Loading...Was the above review useful to you? Yes (32) / No (6)
Wayne a. Wassell
Dec 31, 2014
This customer purchased the item at our site.
I've been using the ZX-1 power add-on for one year now. For its intended function it works great, but the range is limited (2-3 miles). I work in an office environment and occasionally I need to perform field work. When I'm in the office or at home I unhook the ZX-1 and then I'm back to a fully functional manual wheelchair. I'm a T-3 para so I like this ability. Good news is that Spinergy now uses a lithium battery, which doubles the range. If you own one under the old battery system Spinergy can easily convert it to lithium power with a few modifications so you need to contact them, which I have done. Overall I'm satisfied with my ZX-1 and I will be more so when i convert to lithium power and increase my range.

Advantages: 1. Saves your energy.
2. No stress on shoulders.
3. No need to worry about flipping backwards due to the added weight and built in rear-end caster wheel.

Disadvantages: 1. Lose the ability to pop the front caster wheels to get over obstacles.
2. Doesn't always perform well under uneven surface because one wheel may not have proper contact with the ground. In addition, tire slippage can occur on wet grass.
3. Limited range, but this can be corrected by converting to lithium power.
Loading...Was the above review useful to you? Yes (12) / No (2)

Length 24 in.
Width 17.5 in.
Tires Solid/Pneumatic
Max Tire Pressure Indicated on Tire Sidewall
Tire Diameter 10 in.
Maximum User Weight 250 lbs.
Ground Clearance (Frame/Transaxle) 1.75 in./2 in.
Battery Range w/ 250 lb. User 5 Miles with Lead/ 9 Miles with Lithium
Maximum Slope 6 Degrees
Highest Curb Clearance 2 Inches (50mm)
Batteries Lead: 12V 15Ah AGM Lithium: LiFePO4 12V 15Ah
Battery Weight (Pair) 17lbs. w/ Lead, 10lbs. w/ Lithium
Weight (Without Batteries) 65lbs.
Weight (With Batteries) 82lbs. w/ Lead, 75lbs. w/ Lithium
Freewheel Mode Equipped Yes
Electronic Speed Control Equipped Yes
Brake Type Electromechanical Park Brake
Charger Type Off-board
Drivetrain 24V DC Brushed Gear Motors (2)
