Basic Unit |
|||
|
Height Range |
4’0”- 5’6” |
122-168cm |
Youth |
|
Height Range |
5'0"-6'2" |
152-188cm |
Adult |
|
Height Range |
6'-6'10" |
183-211cm |
XT |
|
Weight Limit |
200 lbs. |
90kg |
Youth |
|
Weight Limit |
280 lbs. |
127kg |
Adult |
|
Weight Limit |
350 lbs. |
159kg |
XT |
|
Seat Depth Range (from seat pivot) |
14”-19” |
36-48cm |
Youth |
|
Seat Depth Range (from seat pivot) |
16”-21” |
41-53cm |
Adult |
|
Seat Depth Range (from seat pivot) |
19"-24" |
48-61cm |
XT |
|
Seat to Footplate Range (from seat pivot) |
11”-18” |
28-46cm |
Youth |
|
Seat to Footplate Range (from seat pivot) |
14”-21” |
36-53cm |
Adult |
|
Seat to Footplate Range (from seat pivot) |
17"-23" |
43-58cm |
XT |
|
Knee Width (center to center) |
9” |
23cm |
Youth, Adult, XT |
|
Kneepad Depth Range (from seat pivot) |
3.5”-5.75” |
9-15cm |
Youth, Adult |
|
Kneepad Depth Range (from seat pivot) |
4.75"-7" |
12-18cm |
XT |
|
Seat Height |
21.5” |
55cm |
Youth, Adult |
|
Seat Height |
23.5" |
60cm |
XT |
|
Standard Tray Size |
21”x24” |
53x61cm |
Youth, Adult, XT |
|
Tray/Chest Pad Depth Range (from seat pivot) |
0”-10.5” |
0-27cm |
Youth, Adult |
|
Tray/Chest Pad Depth Range (from seat pivot) |
1"-11" |
3-28cm |
XT |
|
Standard Tray Height Range (from seat pivot) |
15.5”-30.5” |
39-77cm |
Youth, Adult |
|
Standard Tray Height Range (from seat pivot) |
14.5"-31.5" |
37-80cm |
XT |
|
Footprint (caster to caster) |
25”x33” |
64x84cm |
Youth, Adult |
|
Footprint (caster to caster) |
27"x37.5" |
69x95cm |
XT |
|
Weight of Basic Unit |
101 lbs. |
46 kg. |
Youth |
|
Weight of Basic Unit |
104 lbs. |
47 kg. |
Adult |
|
Weight of Basic Unit |
112 lbs. |
51kg |
XT |
|
Frame Color |
Charcoal |
|
Youth, Adult, XT |
|
Standard Upholstery Color |
Black |
|
Youth, Adult, XT |
|
Locking Caster Diameter |
5" |
13cm |
Youth, Adult, XT |
|
Footplates-Plantar |
10 degrees in 3 increments |
(not Glider) |
Youth, Adult, XT |
|
Footplates-Dorsi |
10 degrees in 3 increments |
(not Glider) |
Youth, Adult, XT |
|
Footplates- Toe-out |
15 degrees in 3 increments |
(not Glider) |
Youth, Adult, XT |
Customer feedback
Product rating
Customer Reviews
Sign in to rateCustomers who bought this product also bought
- Colours Razor Blade Jr. Youth Wheelchair
- Wheelchair Tube 24" x 1" (25-540) Schrader Valve each
- ROHO LTV Seat Wheelchair Cushion
- Hollister 30oz Vented Leg Bag System with Fabric Leg Bag Straps - each
- Supracor Stimulite Classic Sling Bottom Cushion Cover
- Aluminum Anodized Wheelchair Handrims - Choose Size and Attachment Types
Detailed images
Send to friend
Basic Unit
Basic Unit |
|||
|
Height Range |
4’0”- 5’6” |
122-168cm |
Youth |
|
Height Range |
5'0"-6'2" |
152-188cm |
Adult |
|
Height Range |
6'-6'10" |
183-211cm |
XT |
|
Weight Limit |
200 lbs. |
90kg |
Youth |
|
Weight Limit |
280 lbs. |
127kg |
Adult |
|
Weight Limit |
350 lbs. |
159kg |
XT |
|
Seat Depth Range (from seat pivot) |
14”-19” |
36-48cm |
Youth |
|
Seat Depth Range (from seat pivot) |
16”-21” |
41-53cm |
Adult |
|
Seat Depth Range (from seat pivot) |
19"-24" |
48-61cm |
XT |
|
Seat to Footplate Range (from seat pivot) |
11”-18” |
28-46cm |
Youth |
|
Seat to Footplate Range (from seat pivot) |
14”-21” |
36-53cm |
Adult |
|
Seat to Footplate Range (from seat pivot) |
17"-23" |
43-58cm |
XT |
|
Knee Width (center to center) |
9” |
23cm |
Youth, Adult, XT |
|
Kneepad Depth Range (from seat pivot) |
3.5”-5.75” |
9-15cm |
Youth, Adult |
|
Kneepad Depth Range (from seat pivot) |
4.75"-7" |
12-18cm |
XT |
|
Seat Height |
21.5” |
55cm |
Youth, Adult |
|
Seat Height |
23.5" |
60cm |
XT |
|
Standard Tray Size |
21”x24” |
53x61cm |
Youth, Adult, XT |
|
Tray/Chest Pad Depth Range (from seat pivot) |
0”-10.5” |
0-27cm |
Youth, Adult |
|
Tray/Chest Pad Depth Range (from seat pivot) |
1"-11" |
3-28cm |
XT |
|
Standard Tray Height Range (from seat pivot) |
15.5”-30.5” |
39-77cm |
Youth, Adult |
|
Standard Tray Height Range (from seat pivot) |
14.5"-31.5" |
37-80cm |
XT |
|
Footprint (caster to caster) |
25”x33” |
64x84cm |
Youth, Adult |
|
Footprint (caster to caster) |
27"x37.5" |
69x95cm |
XT |
|
Weight of Basic Unit |
101 lbs. |
46 kg. |
Youth |
|
Weight of Basic Unit |
104 lbs. |
47 kg. |
Adult |
|
Weight of Basic Unit |
112 lbs. |
51kg |
XT |
|
Frame Color |
Charcoal |
|
Youth, Adult, XT |
|
Standard Upholstery Color |
Black |
|
Youth, Adult, XT |
|
Locking Caster Diameter |
5" |
13cm |
Youth, Adult, XT |
|
Footplates-Plantar |
10 degrees in 3 increments |
(not Glider) |
Youth, Adult, XT |
|
Footplates-Dorsi |
10 degrees in 3 increments |
(not Glider) |
Youth, Adult, XT |
|
Footplates- Toe-out |
15 degrees in 3 increments |
(not Glider) |
Youth, Adult, XT |
Shadow
Shadow |
|||
|
Chest Pad Depth Range (from back) |
6”-14” |
15-36cm |
Youth, Adult, XT |
|
Chest Pad Depth Range - Extra Deep (from back) |
10"-18" |
25-46cm |
Youth, Adult, XT |
|
Chest Pad Height Range-Short (from seat) |
3.5"-6.5" |
9-17cm |
Youth, Adult, XT |
|
Chest Pad Height Range- Tall (from seat) |
6.5"-9.5" |
17-24cm |
Youth, Adult, XT |
|
Tray Height-Short (from seat pivot) |
10.5” |
27cm |
Youth, Adult, XT |
|
Tray Height-Tall (from seat pivot) |
13.5” |
34cm |
Youth, Adult, XT |
|
Weight of Evolv w/Shadow |
115 lbs. |
52 kg. |
Youth, Adult, XT |
|
Shadow Tray Size |
21”x24” |
53x61cm |
Youth, Adult, XT |
Mobile
Mobile |
|||
|
Weight of Mobile Option |
44 lbs. |
20 kg |
Youth, Adult, XT |
|
Weight of Evolv Youth Mobile |
137 lbs. |
63kg |
Youth |
|
Weight of Evolv Adult Mobile |
141 lbs. |
64kg |
Adult, XT |
|
Footprint (including pushrims) |
28.5"x36" |
72x91cm |
Youth, Adult |
|
Footprint (including pushrims) |
30.5"x40.25" |
77x102cm |
XT |
|
Wheelbase |
29.75" |
76cm |
Youth, Adult |
|
Wheelbase |
34.25" |
87cm |
XT |
|
Pushrim Height (from floor) |
45" |
114cm |
Youth, Adult, XT |
|
Wheel Locks |
1/4 turn rotation to lock/unlock |
|
Youth, Adult, XT |
|
Drive Chain Tensioning Method |
Self -Tensioning Gravity Operated |
|
Youth, Adult, XT |
|
Mobile Tray Size |
18"Wx19"L |
46x48cm |
Youth, Adult, XT |
|
Footprint (including pushrims) |
30.5"x40.25" |
77x102cm |
XT |
